| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | FUEL TANK YAMAHA BLACK | 1 | |
| 2 | GRAPHIC SET | 1 | |
| 3 | CAP ASSY 10D5 X 49 | 1 | |
| 4 | CANISTER ASSY | 1 | |
| 5 | GROMMET (JG1) | 2 | |
| 6 | COLLAR (5 per pack) | 2 | |
| 7 | BOLT WITH WASHER | 2 | |
| 8 | ROLL OVER VLV ASSY FOR CAL | 1 | |
| 9 | O-RING FOR CAL | 1 | |
| 10 | HOSE (2HX) | 1 | |
| 11 | HOSE | 1 | |
| 12 | TUBE FLEXIBLE 8AK | 1 | |
| 13 | CLIP | 0 | |
| 14 | CLIP | 1 | |
| 15 | BOLTWITH WASHER | 1 | |
| 16 | DAMPER 1 | 1 |
