CARBURETOR GROUP

Johnson V4T-14B V4T-14B CARBURETOR GROUP

№	Наименование	Кол-во
2	LEAD SHOT	4
3	PLUG	4
4	SCREW UPPER CARBURETOR ONLY	1
5	WASHER MIDDLE CARBURETOR ONLY	1
6	CYLINDER HEAD	1
7	Детать	1
8	SHAFT	1
9	VALVE	4
10	PLUG	4
11	SCREW	16
12	WASHER	1
13	COTTER PIN 10PK Electric Start Models only (010 per pack)	1
14	Детать	1
15	Детать	2
16	WASHER	1
17	BUSHING	3
18	VALVE	4
19	BUSHING	0
20	SCREW UPPER CARBURETOR ONLY	1
21	PIN USED ON MIDDLE CABURETOR	1
22	ARM. & PIN AY	1
23	SLEEVE	1
24	Детать	1
25	LEVER	1
26	RETAINING RIN	4
27	WASHER	1
28	BOW WASHER	1
29	GASKET ALSO AVAILABLE IN CARBURETOR REPAIR KITPART NUMBER 382059	1
30	CLIP	2
31	SCREW	2
32	COVER	1
33	NEEDLE VALVE-S.SPD	4
34	O-RING (005 per pack)	4
36	SPRING	4
37	GASKET ALSO AVAILABLE IN CARBURETOR REPAIR KITPART NUMBER 382059	1
38	SCREW	1
39	BRACKET	1
40	SCREW	3
41	LOCKWASHER	3
42	COVER	1
43	WASHER	4
44	SCREW	12
45	OM	1
46	O-RING	1
47	GASKET ALSO AVAILABLE IN CARBURETOR REPAIR KITPART NUMBER 382059	2
48	HI-SPEED TUBE	4
49	CORE PLUG	1
50	SCREW Early Production	16
51	FLOAT CHAMBER	1
52	Детать	2
53	Детать	4
54	FLOAT ALSO AVAILABLE IN CARBURETOR REPAIR KITPART NUMBER 382059	4
55	VALVE & SEAT ALSO AVAILABLE IN CARBURETOR REPAIR KITPART NUMBER 382059	4
56	O-RINGSCREW PLUG	1
57	GASKET ALSO AVAILABLE IN CARBURETOR REPAIR KITPART NUMBER 382059	1
58	PIN ALSO AVAILABLE IN CARBURETOR REPAIR KITPART NUMBER 382059	4
59	ORIFICE PLUG	4
60	WASHERFIBER	4
61	SCREW	4
62	SCREW	4
63	SOLENOID	1
64	140 HP TNT MODELS ONLY	1
65	TERM.-2973915	2
66	PLATE	1
67	LINK CONTROL KNOB	1
68	LINK&PLUNGER AY	1
69	PLUNGER	1
70	BRACKET	1
71	SCREW	2
72	Детать	4
74	SCREW	1
75	SPACER	1
76	CLAMP	1
77	HOSE	1
78	NUT Electric Start Models	1
79	SCREW	1
80	LEAF PLATE	4
81	SCREW	8
82	CAM SLEEVE	1
84	BUSHING	2
85	SPRING	1
87	COTTER PIN	1
88	YOKE	1
89	ANCHOR PIN	1
90	COTTER PIN 10PK (010 per pack)	1
91	SCREW	9
92	GASKET ALSO AVAILABLE IN CARBURETOR REPAIR KITPART NUMBER 382059	1
93	PLATE	1
94	SCREW	8
95	GASKET	1
96	THROTTLE CAM	1
97	SHIELD	1
98	BELLOW	1
99	CLAMP	1
0382717	Not Shown	1
