| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | HOUSING PISTON | 1 | |
| 3 | BUSHING | 4 | |
| 5 | BOLT | 2 | |
| 7 | LINEBRAKE | 1 | |
| 9 | PAD BRAKE(THICK) | 1 | |
| 11 | PIN CLEVIS | 1 | |
| 13 | ELBOW-FEMALE | 1 | |
| 14 | BUSHING | 1 | |
| 15 | NUT-NYLOK(10) (10 per pack) | 1 | |
| 20 | SHAFT-HELIX | 1 | |
| 24 | SCREW CARRIAGE | 1 | |
| 25 | PLUGMAGNETIC DRAIN | 1 | |
| 26 | CAP STUD COVER | 1 | |
| 28 | BUSHING(10) (10 per pack) | 2 | |
| 29 | SPROCKET 35 T11W (Sport) | 1 | |
| 37 | SEAL OIL(10) (10 per pack) | 2 | |
| 38 | BOLT | 5 | |
| 39 | WASHER SPRING LOCK(10) (10 per pack) | 4 | |
| 42 | SCREW(10) * (10 per pack) | 1 | |
| 43 | NUT | 1 | |
| 45 | RINGRETAINING | 2 | |
| 46 | SPACER SPROCKET | 1 | |
| 48 | CHAIN66P(13W)SILENT (Touring) | 1 | |
| 49 | TIGHTENERCHAINCASE | 1 | |
| 50 | WASHER SPRING | 1 | |
| 51 | NUT SLOTTED | 1 | |
| 52 | PINCOTTER(10) (10 per pack) | 1 | |
| 53 | GASKET-CHAINCASE | 1 | |
| 55 | PLUG(10) (10 per pack) | 1 | |
| 57 | SCREW(10) (10 per pack) | 4 | |
| 58 | SCREW | 1 | |
| 59 | WASHER FLAT | 1 | |
| 60 | NUT-WELL | 1 | |
| 61 | SCREW (Euro) | 2 | |
| 62 | RIVET(50) (50 per pack) | 1 | |
| 63 | SCR-5/16-18 3/4 HXHD/NYLGR8-P | 1 | |
| 64 | WASHERSPRING | 2 | |
| 66 | GUIDE RECOIL | 1 |
