| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 2 | INTAKE GRILL | 1 | |
| 3 | AIR INTAKE ADAPTOR 40 MM | 2 | |
| 4 | LOWER FOAM | 1 | |
| 5 | AIR FILTER | 1 | |
| 6 | CAUTION DECAL AIR INTAKE | 1 | |
| 7 | ANNEAU *GROMMET | 1 | |
| 8 | GROMMET (10.000 per pack) | 1 | |
| 9 | GEMI CLAMP | 2 | |
| 11 | GEMI CLAMP | 2 | |
| 13 | CABLAGE COLLECT*HARNESS-PRESS.MANIF. Includes 4 - 8. | 1 | |
| 14 | SOLENOID LOCK | 1 | |
| 15 | SCREW K40 X 10 (5.000 per pack) | 1 | |
| 16 | STARTER JET | 1 | |
| 23 | SUPPORT | 2 | |
| 24 | Hose, Polyurethane | 0 | |
| 25 | Spring Clamp | 0 | |
| 26 | AIR TEMPERATURE SENSOR | 1 | |
| 27 | CABLAGE TEMP. *HARNESS-TEMP. Includes 22 - 30. MX-Z 600. MX-Z 700. | 1 | |
| 28 | FEMALE TERMINAL HOUSING 2 CIRCUITS | 1 | |
| 29 | FEMALE TERMINAL (10.000 per pack) | 2 | |
| 30 | Wire Seal | 2 | |
| 33 | FEMALE TERMINAL (5.000 per pack) | 0 | |
| 34 | PLUG (5.000 per pack) | 0 | |
| 35 | Vinyl Tubing, Low Temperature (3.000 per pack) | 0 | |
| 36 | FEMALE HOUSING 6 CIRCUITS | 1 | |
| 37 | FEMALE LOCK 6 CIRCUITS | 1 | |
| 38 | DURITE *HOSE | 0 | |
| 39 | CARBURETOR LATCH 700 / 800 MX Z 500. MX Z 800.. | 1 | |
| 40 | ELBOW MALE CONNECTOR (5.000 per pack) | 1 |
