Наименование |
Примечание |
Кол-во |
| 1 |
HELM ASS Y
|
|
1 |
| 2 |
WOODRUFF KEY
|
|
1 |
| 3 |
SUPPORT
|
|
1 |
| 4 |
HEX. SCREW 1/4"-20 X 3/4tahos_ SCOTCH GRIP (5.000 per pack)
|
|
3 |
| 5 |
Flat Washer M6, Stainless
|
|
3 |
| 6 |
Serrated Lock Washer 8 mm
|
|
3 |
| 7 |
HEX. SCREW M6 X 40 (5.000 per pack)
|
|
3 |
| 8 |
Flat Washer M6, Stainless
|
|
6 |
| 9 |
Hex. Elastic Stop Nut M6
|
|
3 |
| 10 |
COLLAR BLACK
|
|
1 |
| 11 |
SCREW 8-32 X 1-1/4" (5.000 per pack)
|
|
2 |
| 12 |
STEERING WHEEL ASS Y Includes 13 to 14
|
|
1 |
| 13 |
CENTER CAP
|
|
1 |
| 16 |
FLAT WASHER STAINLESS (5.000 per pack)
|
|
1 |
| 17 |
LOCK NUT 1/2"-20 (5.000 per pack)
|
|
1 |
| 18 |
CONTR.ULTRAF*CONTROL-ULTRAFLEX Includes 13 - 41.
|
|
1 |
| 19 |
SCREW M5 X 16 (5.000 per pack)
|
|
4 |
| 22 |
COUSSINET *BUSH
|
|
2 |
| 23 |
COUSSINET *BUSH
|
|
2 |
| 24 |
BALL
|
|
1 |
| 25 |
SPRING
|
|
1 |
| 26 |
CAP SCREW
|
|
3 |
| 27 |
FRICTION INSERT
|
|
2 |
| 28 |
BLOCKING PIVOT
|
|
1 |
| 29 |
SPRING
|
|
1 |
| 30 |
THROTTLE LEVER
|
|
1 |
| 31 |
SHIFT LEVER
|
|
1 |
| 32 |
SCREW M5 X 20 (5.000 per pack)
|
|
4 |
| 34 |
LH WATER SEAL (5.000 per pack)
|
|
4 |
| 35 |
THROTTLE LEVER SPACER
|
|
1 |
| 36 |
SHIFT LEVER SPACER
|
|
1 |
| 37 |
RETAINING PLATE
|
|
2 |
| 38 |
HALF-SHIFT HANDLE THREADED
|
|
1 |
| 39 |
HALF-SHIFT HANDLE
|
|
1 |
| 40 |
HALF-THROTTLE HANDLE
|
|
1 |
| 41 |
SCREW M3.5 X 25
|
|
2 |
| 42 |
HALF-THROTTLE HANDLE THREADED
|
|
1 |
| 43 |
CLEVIS L26
|
|
1 |
| 44 |
CLEVIS L25
|
|
1 |
| 45 |
NEUTRAL SWITCH ASS Y
|
|
1 |
| 46 |
SCREW M3 X 6 (5.000 per pack)
|
|
1 |
| 47 |
HEX. SCREW M5 X 16 (5.000 per pack)
|
|
1 |
| 48 |
THROTTLE LINK
|
|
1 |
| 49 |
HEX. ELASTIC NUT M5 (5.000 per pack)
|
|
1 |
| 50 |
PHILLIPS SCREW M5 X 30 (5.000 per pack)
|
|
4 |
| 51 |
PLATE CONTROL
|
|
1 |
| 52 |
CONTROL PLATE INSERT
|
|
1 |
| 53 |
PHILLIPS SCREW M4 X 10 (5.000 per pack)
|
|
4 |
| 54 |
Flat Washer 4 mm
|
|
4 |
| 55 |
RH THROTTLE CABLE
|
|
1 |
| 56 |
Tie-Rap 180 mm
|
|
1 |
| 57 |
CABLE SUPPORT
|
|
1 |
| 58 |
POP RIVET 1/8tahos_ (10.000 per pack)
|
|
2 |
| 59 |
HEX. CAP SCREW M6 X 12 (5.000 per pack)
|
|
1 |
| 60 |
RONDELLE FREIN *WASHER-LOCK 1/4" (5.000 per pack)
|
|
1 |
| 63 |
REVERSE CATCH
|
|
1 |
| 64 |
REVERSE STOPPER
|
|
1 |
| 65 |
REVERSE PIN
|
|
1 |
| 68 |
CABLE SUPPORT
|
|
1 |
| 71 |
LOCK NUT (5.000 per pack)
|
|
1 |
| 72 |
FLAT WASHER 10 MM STAINLESS (5.000 per pack)
|
|
1 |
| 73 |
FLANGED BUSHING
|
|
1 |
| 74 |
PIVOT 3/8tahos_
|
|
1 |
| 75 |
HEX. JAM NUT 5/8"-18
|
|
1 |
| 76 |
CABLE STEERING
|
|
1 |
| 77 |
PIVOT
|
|
1 |
| 78 |
BUSHING (2.000 per pack)
|
|
1 |
| 79 |
FLAT WASHER (5.000 per pack)
|
|
1 |
| 80 |
NUT-STOP ELASTIC MS-17830 (5.000 per pack)
|
|
1 |
| 81 |
HEX. SCREW 1/4"-20 X 1tahos_ SCOTCH GRIP
|
|
1 |
| 84 |
ARM
|
|
1 |
| 85 |
SEAL SWIVEL
|
|
1 |
| 86 |
TERMINAL WIPER
|
|
1 |
| 87 |
BALL JOINT
|
|
1 |
| 88 |
HEX. SCREW M6 X 35 (5.000 per pack)
|
|
1 |
