| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | CUSHION FORE 3 | 1 | |
| 2 | SNAP CARPET | 5 | |
| 3 | WASHER PLASTIC CARP (5 per pack) | 5 | |
| 4 | PAD 1 | 1 | |
| 5 | CLIP 1 UN | 1 | |
| 6 | SCREW TAPPING | 1 | |
| 7 | WASHER FENDER | 1 | |
| 8 | WASHER 1/4" LOCK UN | 1 | |
| 9 | NUT 1/4-20 UN | 1 | |
| 10 | PAD 2 | 1 | |
| 11 | PAD 3 | 1 | |
| 12 | PAD 4 | 1 | |
| 13 | CUSHION SEAT REAR | 1 | |
| 14 | BACKREST 1 | 1 | |
| 15 | CUSHION 1 | 2 | |
| 16 | BACK REST 1 | 2 | |
| 19 | BRACKET SEAT FITTIN | 4 | |
| 20 | SCREW COUNTERSUNK | 8 | |
| 21 | WASHER | 4 | |
| 22 | NUT 10-24 NYLOX | 4 | |
| 23 | PAD 1 | 1 | |
| 24 | PAD 2 | 1 | |
| 25 | BASE DRIVER SEAT | 1 | |
| 26 | SCREW 1/4-20X1 1/4 | 8 | |
| 27 | CUSHION PAD 1 | 1 | |
| 28 | BACK REST 3 | 1 | |
| 29 | BRKT. SEAT | 2 | |
| 30 | SCREW COUNTERSUNK | 6 | |
| 31 | WASHER FENDER (1/4" | 6 | |
| 32 | NUT 1/4-20 | 6 | |
| 33 | BACKREST FRONT PO | 1 | |
| 34 | BACKREST FRONT ST | 1 | |
| 35 | BACKREST FORE 3 | 1 | |
| 36 | LID HATCH | 1 | |
| 37 | BRACKETSEAT | 2 | |
| 38 | BRACKETSEAT | 2 | |
| 39 | SCREW COUNTERSUNK | 12 | |
| 40 | WASHER | 12 | |
| 42 | NUT | 12 | |
| 43 | SCREW COUNTERSUNK | 8 | |
| 44 | EYE STRAP | 2 | |
| 46 | LID HATCH | 1 |
