| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | TANK WATER | 1 | |
| 2 | PLUG | 1 | |
| 3 | JOINT HOSE 2 | 2 | |
| 4 | HOSE 1 | 2 | |
| 5 | HOSE CLAMP ASSY | 4 | |
| 6 | FLOOR DRAIN | 2 | |
| 7 | PACKING SEAL | 2 | |
| 8 | SCREW 1/4-20 X 1 | 14 | |
| 9 | WASHER FENDER | 14 | |
| 10 | PUMP BALLAST | 1 | |
| 11 | SCREW10-24 X 1-1/2 | 4 | |
| 12 | WASHER tahos_10 FLAT (5 per pack) | 4 | |
| 13 | NUT INSERT | 4 | |
| 14 | WASHER | 4 | |
| 15 | NUT 10-24 NYLOX | 4 | |
| 16 | HOSE ASSY. | 2 | |
| 17 | HOSE 1 | 1 | |
| 18 | BODY DRAIN 1 | 1 | |
| 19 | BODY DRAIN 1 | 1 | |
| 20 | CLAMP | 2 | |
| 21 | HOSE ASSY. | 1 | |
| 22 | HOSE 1 | 1 | |
| 26 | FLOOR DRAIN ASSY. | 3 | |
| 27 | FLOOR DRAIN ASSY. | 3 | |
| 28 | HOSE 1 | 1 | |
| 38 | LEVER COCK | 1 | |
| 39 | HOSE 1 | 1 | |
| 41 | TANK WATER | 1 | |
| 43 | SCREW TAPPING | 4 | |
| 45 | HOSE 1 | 1 | |
| 46 | BAND | 2 | |
| 47 | LEVER COCK | 1 |
