Наименование |
Примечание |
Кол-во |
| 5 |
Hex. Flanged Screw M6 X 16, Scotch Grip
|
|
6 |
| 8 |
HEX. FLANGED SCREW M6 X 16 (10.000 per pack)
|
|
10 |
| 10 |
HEX. FLANGED SCREW M6 X 20 (10.000 per pack)
|
|
8 |
| 11 |
HEX. FLANGED SCREW M6 X 30 (5.000 per pack)
|
|
2 |
| 12 |
HEX. FLANGED SCREW M8 X 20 (10.000 per pack)
|
|
8 |
| 13 |
HEX. FLANGED SCREW M8 X 35 Except XMR
|
|
2 |
| 15 |
CARRIAGE BOLT M6 X 35 (10.000 per pack)
|
|
8 |
| 16 |
CARRIAGE BOLT M8 X 20
|
|
2 |
| 18 |
FLAT WASHER (10.000 per pack)
|
|
8 |
| 19 |
Hex. Elastic Stop Nut M6
|
|
4 |
| 24 |
FLANGED ELASTIC NUT M6 (8.000 per pack)
|
|
38 |
| 25 |
Hex. Flanged Elastic Nut M8
|
|
16 |
| 27 |
Flat Washer 6 mm
|
|
8 |
| 29 |
Hex. Screw M8 X 20
|
|
2 |
| 30 |
SCREW K40 X 10 (5.000 per pack)
|
|
4 |
| 31 |
Panel Nut M6 X 1.0
|
|
4 |
| 32 |
TORX SCREW M6 X 20 Model-RT STD
|
|
7 |
| 33 |
TRUSS HEAD TORX SCREW K50 X 16 (5.000 per pack)
|
|
8 |
| 36 |
TORX SCREW M8 X 30
|
|
4 |
| 38 |
Elastic Nut Housing M8
|
|
4 |
| 39 |
Tuflok Plastic Rivet
|
|
22 |
| 40 |
Pop Rivet 3/16"
|
|
4 |
| 41 |
RUBBER COVER
|
|
2 |
| 42 |
INSERT Except XMR
|
|
8 |
| 43 |
Rubber Bumper
|
|
2 |
| 45 |
Edge Clip
|
|
8 |
| 47 |
GROMMET
|
|
4 |
| 48 |
ENGINE COVER
|
|
1 |
| 49 |
DASH SUPPORT KIT
|
|
1 |
| 49 |
DASH SUPPORT KIT
|
|
1 |
| 50 |
QUARRY GRAY LH LATERAL PANEL Quarry Gray Model
|
|
1 |
| 50 |
PANNEAU GAUCHE *LH.PANEL Camo Model
|
|
1 |
| 51 |
PANNEAU DROIT *RH.PANEL Camo Model
|
|
1 |
| 51 |
QUARRY GRAY RH LATERAL PANEL Quarry Gray Model
|
|
1 |
| 60 |
LH EXTENSION PANNEL
|
|
1 |
| 61 |
FRONT BUMPER P-XTP P-LTD P-XT except Black Model
|
|
1 |
| 62 |
LH SUPPORT ASS Y
|
|
1 |
| 63 |
RH SUPPORT ASS Y
|
|
1 |
| 68 |
CAPUCHON *CAP
|
|
1 |
| 69 |
CAPUCHON *CAP
|
|
1 |
| 70 |
RING
|
|
2 |
| 71 |
LUGAGE RACK MOULDING Except XMR
|
|
1 |
| 72 |
LH INNER FENDER
|
|
1 |
| 72 |
RH INNER FENDER
|
|
1 |
| 74 |
LOWER FENDER SUPPORT
|
|
2 |
| 76 |
RH INNER FENDER
|
|
1 |
| 76 |
LH INNER FENDER
|
|
1 |
| 77 |
BRACKET COVER
|
|
4 |
| 82 |
MARCHEPIED DR. *RH.FOOTBOARD
|
|
1 |
| 82 |
MARCHEPIED GA. *LH.FOOTBOARD
|
|
1 |
| 84 |
SHIFTER GATE KIT Except T3
|
|
1 |
| 84 |
SHIFTER GATE KIT T3
|
|
0 |
| 85 |
BLACK FRONT BUMPER SUPPORT
|
|
1 |
| 88 |
TUBE *TUBE Except XMR
|
|
2 |
| 89 |
TUBE *TUBE Except XMR
|
|
2 |
| 93 |
LH AIR DEFLECTOR
|
|
1 |
| 94 |
RH AIR DEFLECTOR Package Pro XMR
|
|
1 |
| 96 |
PLAQUE *PLATE Except Europe Model
|
|
1 |
| 107 |
CONSOLE CAP KIT North America
|
|
1 |
| 110 |
CARGO RACK CENTER SUPPORT Except XMR
|
|
1 |
| 118 |
RH FOOTREST Except XMR 850
|
|
1 |
| 118 |
LH FOOTREST Except XMR 850
|
|
1 |
| 119 |
FRONT FACIA
|
|
1 |
| 120 |
GAUGE SUPPORT P-XMR 650 850
|
|
1 |
| 125 |
PROTECTIVE PLATE KIT
|
|
1 |
| 129 |
GREY HOOD ASS Y Model-International
|
|
1 |
| 129 |
BREAKUP COUNTRY CAMO HOOD ASS Y Model-International
|
|
1 |
| 129 |
BREAKUP COUNTRY CAMO HOOD KIT Model-North America
|
|
1 |
| 132 |
CAMO BREAKUP COUNTRY LH FRONT FENDER KIT Model-North America
|
|
1 |
| 132 |
GREY RH FRONT FENDER ASS Y Quarry Gray Model International
|
|
1 |
| 132 |
BREAKUP COUNTRY CAMO RH FRONT FENDER KIT Camo Model North America
|
|
1 |
| 132 |
CAMO BREAKUP COUNTRY LH FRONT FENDER ASS Model-International
|
|
1 |
| 132 |
AILE AV. *FR. FENDER Model-International
|
|
1 |
| 132 |
BREAKUP COUNTRY CAMO FRONT FENDER ASS Model-International
|
|
1 |
| 134 |
TORX SCREW M6 X 35 BZN Model Jet Black
|
|
16 |
| 135 |
Hex. Flanged Screw M6x70 Scotch Grip
|
|
2 |
| 136 |
GREY LH REAR FENDER Model-International
|
|
1 |
| 136 |
BREAKUP COUNTRY CAMO LH REAR FENDER KIT Model-North America
|
|
1 |
| 136 |
BREAKUP COUNTRY CAMO LH REAR FENDER ASSY Model-International
|
|
1 |
| 136 |
GREY RH REAR FENDER Model-International
|
|
1 |
| 136 |
GREY RH REAR FENDER Model-North America
|
|
1 |
| 136 |
BREAKUP COUNTRY CAMO RH REAR FENDER ASSY Model-International
|
|
1 |
| 143 |
REAR RACK KIT North America
|
|
2 |
| 143 |
REAR RACK KIT Model-International
|
|
2 |
| 144 |
COFFRE ASSEMBLÉ*ASS Y BOX MAX Model
|
|
1 |
| 145 |
NEOPRENE SEAL MAX Model
|
|
0 |
| 146 |
TOOL KIT
|
|
1 |
| 147 |
REMOTE CONTROL
|
|
1 |
| 148 |
ADJUSTEMENT WRENCH
|
|
1 |
