Наименование |
Примечание |
Кол-во |
| 1 |
SOCKET SCREW M10 X 35 (10.000 per pack)
|
|
2 |
| 2 |
SOCKET HEAD SCREW M8 X 20 (10.000 per pack)
|
|
4 |
| 3 |
Hex. Screw M6 X 55
|
|
8 |
| 4 |
HEX. SCREW M6 X 60 Model-SE (25.000 per pack)
|
|
4 |
| 5 |
HEX. SCREW M8 X 35 (10.000 per pack)
|
|
0 |
| 6 |
Hex. Flanged Screw M8 X 20, Scotch Grip
|
|
2 |
| 7 |
HEX. FLANGED SCREW M8 X 20 SCOTCH GRIP
|
|
4 |
| 8 |
HEX. FLANGED SCREW M8 X 40 SCOTCH GRIP (10.000 per pack)
|
|
4 |
| 9 |
Hex. Flanged Screw M10 X 25
|
|
0 |
| 10 |
HEX. FLANGED SCREW M10 X 30 Formula Deluxe 670. (10.000 per pack)
|
|
2 |
| 11 |
Hex. Flanged Screw M6 X 16
|
|
0 |
| 12 |
Hex. Flanged Screw M6 X 20
|
|
0 |
| 13 |
Hex. Flanged Screw M6 X 25
|
|
2 |
| 14 |
HEX. FLANGED SCREW M8 X 20 (10.000 per pack)
|
|
2 |
| 15 |
Hex. Flanged Screw M8 X 25
|
|
4 |
| 16 |
HEX. FLANGED SCREW M8 X 45 (10.000 per pack)
|
|
4 |
| 17 |
HEX. FLANGED SCREW M8 X 50 Not Shown (10.000 per pack)
|
|
1 |
| 18 |
HEX. FLANGED SCREW M8 X 60 (10.000 per pack)
|
|
2 |
| 19 |
CARRIAGE BOLT M8 X 70 (10.000 per pack)
|
|
2 |
| 20 |
Hex. Flanged Screw M6 X 12
|
|
5 |
| 21 |
HEX. FLANGED SCREW M6 X 16 (10.000 per pack)
|
|
2 |
| 22 |
HEX. NUT (4.000 per pack)
|
|
4 |
| 23 |
Elastic Stop Nut M6
|
|
2 |
| 24 |
Hex. Elastic Stop Nut M8
|
|
4 |
| 25 |
HEX. FLANGED ELASTIC NUT M10 (10.000 per pack)
|
|
4 |
| 26 |
Hex. Flanged Elastic Nut M6
|
|
0 |
| 27 |
Hex. Flanged Elastic Nut M8
|
|
0 |
| 28 |
Flat Washer 8 mm
|
|
0 |
| 29 |
WASHER-LOCK DIN.127B (50.000 per pack)
|
|
4 |
| 30 |
TORX SCREW M8 X 25 (2.000 per pack)
|
|
4 |
| 31 |
HEX. SCREW K50 X 45 (4.000 per pack)
|
|
2 |
| 32 |
Plastite Screw Type K-40 M4 X 25
|
|
11 |
| 33 |
SCREW PLASTITE TYPE K-40 M4 X 16 (2.000 per pack)
|
|
0 |
| 34 |
ENGINE COVER SUPPORT
|
|
2 |
| 35 |
TRUSS HEAD TORX SCREW K50 X 16 (5.000 per pack)
|
|
3 |
| 36 |
TORX TRUSS SCREW M6 X 50 (4.000 per pack)
|
|
2 |
| 37 |
TORX SCREW M6 X 16 (12.000 per pack)
|
|
18 |
| 38 |
TORX SCREW M8 X 25 SCOTCH GRIP (4.000 per pack)
|
|
4 |
| 39 |
HEX. FLANGED SCREW M6 X 25 (8.000 per pack)
|
|
0 |
| 40 |
TORX SCREW M8 X 35 (4.000 per pack)
|
|
4 |
| 41 |
PANEL NUT M8 (5.000 per pack)
|
|
4 |
| 42 |
FLAT WASHER (3.000 per pack)
|
|
2 |
| 43 |
FLAT WASHER
|
|
10 |
| 44 |
CLEVIS PIN Package-XT XTP LTD PRO
|
|
1 |
| 45 |
COTTER PIN Package-XT XTP LTD PRO (25.000 per pack)
|
|
1 |
| 46 |
PLASTIC CAP STD (5.000 per pack)
|
|
1 |
| 47 |
Tuflok Plastic Rivet
|
|
0 |
| 48 |
Grommet
|
|
5 |
| 49 |
HEX. SCREW 12 X 3/4 (10.000 per pack)
|
|
2 |
| 50 |
Pop Rivet 3/16"
|
|
4 |
| 51 |
RONDELLE *WASHER (50.000 per pack)
|
|
7 |
| 52 |
Flat Washer
|
|
2 |
| 53 |
CAP (10.000 per pack)
|
|
1 |
| 54 |
RONDELLE *WASHER (25.000 per pack)
|
|
2 |
| 55 |
PROTECTOR CAP
|
|
1 |
| 56 |
Edge Clip
|
|
9 |
| 57 |
KNOB (6.000 per pack)
|
|
5 |
| 58 |
Oval Washer
|
|
8 |
| 59 |
BLACK DASH-BOARD KIT
|
|
1 |
| 60 |
YELLOW LH SIDE PANEL Model-Yellow
|
|
1 |
| 60 |
RED LH SIDE PANEL Model-Red
|
|
1 |
| 61 |
YELLOW RH SIDE PANEL Model-Yellow
|
|
1 |
| 61 |
RED RH SIDE PANEL Model-Red
|
|
1 |
| 63 |
LH INNER FENDER
|
|
1 |
| 64 |
REFLECTIVE SHEET
|
|
1 |
| 67 |
WINCH ROLLER Package-XT XTP LTD PRO
|
|
1 |
| 68 |
RED REAR FENDER KIT Model-Red International
|
|
1 |
| 68 |
YELLOW REAR FENDER KIT Model-Yellow International
|
|
1 |
| 69 |
BLACK WINCH BRACKET
|
|
1 |
| 70 |
FRONT LUGGAGE RACK
|
|
1 |
| 71 |
REAR LUGGAGE RACK
|
|
1 |
| 72 |
BLACK LH CAP
|
|
1 |
| 73 |
YELLOW STORAGE TRAY Model-Yellow
|
|
1 |
| 73 |
RED STORAGE TRAY Model-Red
|
|
1 |
| 74 |
FRONT CAP
|
|
2 |
| 75 |
REFLECTIVE SHEET
|
|
1 |
| 76 |
BUSHING
|
|
4 |
| 77 |
REFLECTIVE SHEET
|
|
1 |
| 79 |
HOOK Package-XT XTP LTD PRO
|
|
1 |
| 81 |
RH FOOTBOARD
|
|
1 |
| 82 |
REFLECTIVE SHEET
|
|
1 |
| 83 |
CONSOLE CAP
|
|
1 |
| 85 |
INNER FENDER
|
|
1 |
| 86 |
MUFFLER COVER
|
|
1 |
| 87 |
RH HANDLE
|
|
1 |
| 88 |
LH HANDLE
|
|
1 |
| 89 |
RH FIXATION PLATE
|
|
1 |
| 90 |
LH FIXATION PLATE
|
|
1 |
| 91 |
YELLOW FRONT FASCIA Model-Yellow
|
|
1 |
| 91 |
RED FRONT FASCIA Model-Red
|
|
1 |
| 92 |
UPPER GRILL
|
|
1 |
| 95 |
FRONT BUMBER Model-XT
|
|
1 |
| 97 |
REAR BUMBER Model-XT
|
|
1 |
| 98 |
LH FRONT CAP Model-XT
|
|
2 |
| 99 |
RH FRONT CAP Model-XT
|
|
2 |
| 100 |
LH HEAD LAMP SUPPORT
|
|
1 |
| 101 |
RH HEAD LAMP SUPPORT
|
|
1 |
| 102 |
LH FACIA SUPPORT
|
|
1 |
| 102 |
RH FACIA SUPPORT
|
|
1 |
| 103 |
LH LOWER FRONT FACIA International
|
|
1 |
| 104 |
RH LOWER FRONT FACIA International
|
|
1 |
| 105 |
GUARD PLATE Model-STD
|
|
1 |
| 105 |
GUARD PLATE Model-XT
|
|
1 |
| 106 |
LH ANCHOR PLATE
|
|
1 |
| 106 |
RH ANCHOR PLATE
|
|
1 |
| 107 |
REFLECTIVE SHEET
|
|
1 |
| 108 |
REFLECTIVE SHEET
|
|
1 |
| 109 |
LEVER INDICATOR
|
|
1 |
| 110 |
REFLECTIVE SHEET
|
|
1 |
| 111 |
REFLECTIVE SHEET
|
|
1 |
| 112 |
LH LOWER FACIA SUPPORT
|
|
1 |
| 112 |
RH LOWER FACIA SUPPORT
|
|
1 |
| 113 |
REFLECTIVE SHEET
|
|
1 |
| 114 |
REFLECTIVE SHEET
|
|
1 |
| 115 |
REFLECTIVE SHEET
|
|
1 |
| 116 |
REFLECTIVE SHEET
|
|
1 |
| 117 |
REFLECTIVE SHEET
|
|
1 |
| 118 |
REFLECTIVE SHEET
|
|
1 |
| 119 |
GROMMET
|
|
2 |
| 121 |
LH FOOTBOARD
|
|
1 |
| 122 |
U REINFORCEMENT
|
|
2 |
| 123 |
PLAQUE RENFORT *REINFORCEMENT Model-XT
|
|
1 |
| 124 |
FRONT BUMPER
|
|
1 |
| 125 |
FRONT SUPPORT
|
|
1 |
| 126 |
REAR SUPPORT
|
|
1 |
| 127 |
RUBBER GROMMET
|
|
2 |
| 128 |
RUBBER CAP
|
|
2 |
| 129 |
LINK PLATE Model-XT
|
|
2 |
| 130 |
FOOTREST
|
|
4 |
| 131 |
BUMPER BRACKET Model-XT
|
|
2 |
| 132 |
REFLECTIVE SHEET
|
|
1 |
| 133 |
ENGINE COVER
|
|
1 |
| 134 |
REAR FACIA Model-XT
|
|
1 |
| 135 |
COUVRE FIL *THREAD COVER
|
|
1 |
| 136 |
RED FRONT FENDER KIT Model-Red International
|
|
1 |
| 136 |
YELLOW FRONT FENDER KIT Model-Yellow International
|
|
1 |
| 137 |
REFLECTIVE SHEET
|
|
1 |
| 139 |
SKID PLATE KIT
|
|
1 |
| 140 |
COSSE A ANNEAU *OPEN BARIL XT
|
|
1 |
| 141 |
SHRINK TUBING
|
|
0 |
| 142 |
OPEN BARELL
|
|
1 |
| 143 |
WINCH CABLE ASS Y Model-XT
|
|
1 |
| 144 |
Push Nut
|
|
2 |
| 145 |
WINCH Model-XT
|
|
1 |
| 146 |
BLACK MOUNTING PLATE Model-XT
|
|
1 |
