Наименование |
Примечание |
Кол-во |
| 1 |
SOCKET SCREW M8 X 30 Package XMR Engine 1000 (5.000 per pack)
|
|
2 |
| 2 |
SOCKET HEAD SCREW M8 X 60 (2.000 per pack)
|
|
2 |
| 3 |
SCREW-SOCKET HD.CTSK.DIN.7991
|
|
2 |
| 4 |
SOCKET HEAD SCREW M4 X 40 SM5 (10.000 per pack)
|
|
2 |
| 5 |
HEX. SCREW M8 X 60 Except Package XMR Engine 1000R (4.000 per pack)
|
|
4 |
| 6 |
HEX. SCREW M8 X 30 Package XMR Engine 1000 (5.000 per pack)
|
|
2 |
| 7 |
Hex. Flanged Screw M8 X 20, Scotch Grip
|
|
0 |
| 8 |
Hex. Flanged Screw M6 X 20
|
|
2 |
| 9 |
HEX. FLANGED SCREW M8 X 20 (10.000 per pack)
|
|
2 |
| 10 |
Hex. Flanged Screw M8 X 25
|
|
2 |
| 11 |
HEX. FLANGED SCREW M8 X 35 (10.000 per pack)
|
|
1 |
| 12 |
Flat Washer
|
|
4 |
| 13 |
COTTER PIN (50.000 per pack)
|
|
4 |
| 14 |
Elastic Stop Nut M4
|
|
0 |
| 15 |
HEX. ELASTIC NUT M5 (5.000 per pack)
|
|
2 |
| 16 |
Hex. Elastic Stop Nut M6
|
|
4 |
| 17 |
Hex. Flanged Nut M8
|
|
2 |
| 18 |
Hex. Flanged Elastic Nut M8
|
|
0 |
| 19 |
Hex. Elastic Flanged Nut M8
|
|
4 |
| 21 |
CONICAL SPRING WASHER M8 (10.000 per pack)
|
|
4 |
| 22 |
HEX. FLANGED SCREW K40 X 25 Package XT -LTD (5.000 per pack)
|
|
4 |
| 23 |
HEX. FLANGED ELASTIC NUT M12
|
|
1 |
| 24 |
Torx Screw M5 X 14
|
|
2 |
| 25 |
TORX SCREW M6 X 16 (5.000 per pack)
|
|
2 |
| 27 |
NUT M12
|
|
4 |
| 28 |
Flat Washer
|
|
1 |
| 29 |
O-RING
|
|
4 |
| 37 |
U-CLAMP
|
|
2 |
| 39 |
HANDLE GUARD ASS Y XT Package XT
|
|
1 |
| 41 |
BRACKET SMALL Package XMR - XTP
|
|
2 |
| 42 |
BRACKET LARGE Package XMR - XTP
|
|
2 |
| 43 |
LH MIRROR Europe Model
|
|
1 |
| 44 |
RH MIRROR Europe Model
|
|
1 |
| 45 |
FOAM Package XTP
|
|
1 |
| 47 |
EMBOUT GUIDON *END-PIECE Package PRO - STD - LTD - XT
|
|
2 |
| 48 |
BALL JOINT LH THREADS Except Package XMR
|
|
1 |
| 50 |
BALL JOINT
|
|
2 |
| 51 |
DPS DECAL Package XT - LTD
|
|
1 |
| 52 |
HANDLE GRIP Except Package LTD
|
|
2 |
| 53 |
SUPPORT Package XMR Engine 1000
|
|
2 |
| 54 |
STEERING SUPPORT Package XMR Engine 1000
|
|
2 |
| 55 |
RENFORT *STIFFENER
|
|
2 |
| 56 |
HANDLE BAR Package XT-P
|
|
1 |
| 56 |
GUIDON NOIR *BAR-HANDLE Package PRO-XT-STD-DPS-LTD
|
|
1 |
| 57 |
COVER Package-XXC Black
|
|
1 |
| 59 |
RH AIR DEFLECTOR (Xxc )
|
|
1 |
| 60 |
LH AIR DEFLECTOR (Xxc )
|
|
1 |
| 62 |
BELLOWS Except Package STD
|
|
1 |
| 63 |
ARBRE DIRECTION*TUBE-MAIN Except Package STD
|
|
1 |
| 65 |
SPHERICAL HALF BUSHING
|
|
4 |
| 67 |
UPPER COLUMN ATTACHMENT
|
|
1 |
| 68 |
POWER STEERING MODULE BRACKET
|
|
1 |
| 69 |
COLUMN ATTACHMENT
|
|
1 |
| 70 |
STEERING SUPPORT
|
|
4 |
| 72 |
STEERING COVER Package STD DPS PRO
|
|
1 |
| 73 |
RH STEERING BRACKET
|
|
1 |
| 74 |
HEAT DEFLECTOR Except Package STD
|
|
1 |
| 76 |
HANDLE BAR PROTECTOR Package XT-LTD
|
|
1 |
| 77 |
TIE-ROD ASS Y Except Package XMR
|
|
1 |
| 79 |
POWER STEERING
|
|
1 |
| 80 |
ENS. BARRE*PITMAN ARM KIT VTT G2
|
|
1 |
| 101 |
AIR DEFLECTOR SUPPORT KIT
|
|
2 |
