Наименование |
Примечание |
Кол-во |
| 1 |
RH FRONT CALIPER ASS Y
|
|
1 |
| 2 |
RH BRAKE PAD KIT
|
|
1 |
| 3 |
PIN SET
|
|
1 |
| 4 |
BLEEDING SCREW
|
|
1 |
| 5 |
RESSORT *SPRING
|
|
1 |
| 6 |
LH FRONT CALIPER ASS Y
|
|
1 |
| 10 |
LH BRAKE PAD KIT
|
|
1 |
| 11 |
LH FRONT MASTER CYLINDER ASS Y
|
|
1 |
| 12 |
LEVER SET
|
|
1 |
| 13 |
CLAMP AND SCREW KIT
|
|
1 |
| 14 |
CAP SET
|
|
1 |
| 15 |
RH FRONT MASTER CYLINDER ASS Y
|
|
1 |
| 16 |
LEVER SET
|
|
1 |
| 18 |
KIT SWITCH
|
|
1 |
| 20 |
LH BRAKE LINE
|
|
1 |
| 21 |
RH BRAKE LINE
|
|
1 |
| 22 |
LH BRAKE HANDLE LINE ASS Y Model-Europe
|
|
1 |
| 23 |
CLAMP
|
|
1 |
| 24 |
RH BRAKE HANDLE LINE ASS Y Model-Europe
|
|
1 |
| 26 |
Banjo Bolt (M10 x 1.25 thread)
|
|
9 |
| 27 |
BANJO BOLT Model-Europe
|
|
2 |
| 28 |
COPPER WASHER (10.000 per pack)
|
|
27 |
| 29 |
HEX. SCREW M10 X 14 SCOTCH GRIP Model-Europe
|
|
1 |
| 30 |
BRAKE LINE Model-Europe
|
|
1 |
| 31 |
OUTLET HOSE MASTER CYLINDER Model-Europe
|
|
1 |
| 32 |
RH REAR BRAKE LINE ASS Y Model-Europe
|
|
1 |
| 34 |
TUBING 10 MM
|
|
0 |
| 35 |
REAR CYLINDER MASTER ASS Y Europe Includes 100 to 100b
|
|
1 |
| 36 |
OIL TANK
|
|
1 |
| 37 |
HOUSING OIL HOSE
|
|
1 |
| 38 |
GROMMET (5.000 per pack)
|
|
1 |
| 39 |
BUSHING
|
|
1 |
| 40 |
FLANGED HEX. SCREW M5 X 20
|
|
1 |
| 41 |
Flat Washer
|
|
1 |
| 42 |
FLANGED ELASTIC NUT M5 (4.000 per pack)
|
|
1 |
| 43 |
SPLITTER Model-Europe
|
|
2 |
| 44 |
HEX. SCREW M6 X 40 (10.000 per pack)
|
|
4 |
| 45 |
Tie-Rap 180 mm
|
|
2 |
| 46 |
Pop Rivet 3/16"
|
|
2 |
| 47 |
Brake Switch
|
|
1 |
| 48 |
RH REAR CALIPER ASS Y
|
|
1 |
| 53 |
HEX. FLANGED SCREW M10 X 20
|
|
2 |
| 54 |
BRAKE PEDAL
|
|
1 |
| 55 |
BRAKE PEDAL SPRING
|
|
1 |
| 56 |
Hex. Flanged Screw M6 X 20
|
|
1 |
| 57 |
Hex. Flanged Elastic Nut M6
|
|
1 |
| 58 |
O-RING
|
|
2 |
| 59 |
SHOULDER SCREW M10
|
|
1 |
| 60 |
Hex. Flanged Elastic Nut M10
|
|
1 |
| 61 |
HEX. FLANGED SCREW M8 X 55 (2.000 per pack)
|
|
2 |
| 62 |
Hex. Flanged Elastic Nut M8
|
|
2 |
| 63 |
Torx Screw M8 X 16, Scotch Grip
|
|
8 |
| 64 |
DISC BRAKE
|
|
2 |
| 67 |
HEX. FLANGED SCREW M10 X 25
|
|
4 |
| 69 |
Flat Washer 6 mm
|
|
1 |
| 71 |
BRACKET BRAKE PEDAL
|
|
1 |
| 72 |
CARRIAGE BOLT M8 X 20
|
|
3 |
| 74 |
FRONT HOSE PROTECTOR
|
|
2 |
| 75 |
TORX SCREW M5 X 20 (10.000 per pack)
|
|
4 |
| 76 |
WASHER M5 (10.000 per pack)
|
|
4 |
| 77 |
PANEL NUT M5 X 0.8 (10.000 per pack)
|
|
4 |
| 78 |
LH HOSE BRACKET
|
|
1 |
| 79 |
RH HOSE BRACKET
|
|
1 |
| 80 |
REAR HOSE PROTECTOR
|
|
1 |
| 81 |
TORX SCREW M5 X 20 (6.000 per pack)
|
|
2 |
| 83 |
Elastic Flanged Nut M5
|
|
2 |
| 84 |
TORX SCREW M6 X 16 (12.000 per pack)
|
|
1 |
| 85 |
FRONT HOSE BRACKET
|
|
1 |
| 86 |
Panel Nut M6 X 1.0
|
|
1 |
| 87 |
Flanged Screw M6 X 20 Scotch Grip
|
|
1 |
| 88 |
CLAMP Model-Europe
|
|
2 |
| 89 |
Clamp
|
|
4 |
| 90 |
TIE RAP 533 MM (20.000 per pack)
|
|
1 |
