№ | Наименование | Примечание | Кол-во |
---|---|---|---|
002 | CLIP THROTTLE CABLE | 0 | |
003 | RUBBER | 2 | |
005 | TRAY BATTERY | 1 | |
006 | BAND CABLE | 0 | |
007 | FRAME *R110* (MONZA RED) | 0 | |
008 | RUB ENGINE SETTING | 0 | |
009 | CLIP A BRAKE PIPE | 0 | |
010 | CLIP C, BRAKE PIPE | 2 | |
011 | RUBBER B SETTING | 0 | |
012 | CLIP D BRAKE PIPE | 0 | |
013 | E-CLIP BRAKE PIPE | 0 | |
014 | CLIP A WIRE | 1 | |
015 | CLIP B WIRE | 1 | |
016 | CLIP WIRE HARNESS | 0 | |
017 | BOX BATTERY | 0 | |
018 | PLATE SKID | 0 | |
019 | BAND SKID PLATE | 0 | |
021 | PLATE A ELECTRIC | 0 | |
024 | PAD FR. CROSS PIPE | 0 | |
025 | RUBBER, TAILLIGHT | 2 | |
026 | RUBBER, BATTERY BOX | 2 | |
027 | LABEL HOT WARNING | 2 | |
028 | LABEL TRANSMISSION | 2 | |
029 | MARK | 1 | |
030 | LABEL RESERVE | 1 | |
031 | LABEL | 1 | |
032 | BOLT FLANGE (10X55) | 5 | |
033 | BOLT, FLANGE (8X20) | 6 | |
034 | COLLAR | 2 | |
034 | COLLAR | 2 | |
035 | CLAMP TUBE | 0 | |
036 | BAND, WIRE HARNESS | 2 | |
038 | SCREW, PAN (4X10) | 1 | |
039 | Гайка с фланцем | 5 | |
040 | BOLT, FLANGE (6X12) | 1 | |
042 | BOLT, FLANGE (6X12) | 2 | |
042 | BOLT FLANGE (6X12) | 2 | |
043 | BOLT, FLANGE (6X28) | 2 | |
043 | BOLT FLANGE (6X28) | 2 | |
044 | BOLT, FLANGE (8X16) | 1 | |
044 | BOLT FLANGE (8X16) | 1 |
