| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1-1 | FENDERFRONT | 1 | |
| 1-2 | FENDERFRONT | 1 | |
| 1-3 | Деталь | 1 | |
| 1-4 | Деталь | 1 | |
| 1-5 | Деталь | 1 | |
| 2 | SCREW | 10 | |
| 3 | NUT | 10 | |
| 4 | GROMMET | 2 | |
| 5 | BOLT | 2 | |
| 6 | WASHER | 2 | |
| 7 | COVERFRONT FEN | 1 | |
| 8 | COVERFRONT FEN | 1 | |
| 11 | BOLT | 4 | |
| 12 | BOLT | 2 | |
| 13 | (CA)SPACER 6.5X | 2 | |
| 14 | CUSHION | 2 | |
| 15 | SCREW | 2 | |
| 16 | MUDGUARDFR FEN | 1 | |
| 17 | MUDGURDFRONT F | 1 | |
| 18 | CLIP | 22 | |
| 19 | BRACE COMPFRON | 1 | |
| 20 | BRACE COMPFRON | 1 | |
| 21 | BOLT | 4 | |
| 22 | SCREW | 2 | |
| 23 | WASHER8.5X20X1 | 2 | |
| 24 | MUDFLAPFRONT F | 1 | |
| 25 | MUDFLAPFRONT F | 1 | |
| 26 | SCREW | 6 | |
| 27 | WASHER 5.5X20X (0010 per pack) | 8 | |
| 28-1 | NUT (0010 per pack) | 10 | |
| 29-1 | GUARDMUFFLER F | 1 | |
| 30 | MUDFLAPFR INNE | 1 | |
| 31 | MUDFLAPFR INNE | 1 | |
| 32 | SCREW | 6 | |
| 33 | CHAIN CASE WASH | 6 | |
| 34 | CAP | 4 | |
| 35 | Деталь | 2 | |
| 36-1 | Деталь | 2 | |
| 36-2 | EMBLEMFRONT FE | 2 | |
| 37-1 | Деталь | 2 | |
| 37-2 | Деталь | 2 | |
| 38-1 | EMBLEMFRONT FE | 2 | |
| 38-2 | Деталь | 2 |
