| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | JOINT CARB. 1 | 1 | |
| 2 | JOINTCARBURETOR 2 | 1 | |
| 3 | O-RING (2TY) | 2 | |
| 4 | PLUGBLIND | 1 | |
| 5 | CLIPSCISSOR | 1 | |
| 6 | BOLT (4FL) | 4 | |
| 7 | HOSE CLAMP ASSY | 2 | |
| 8 | AIR CLNR CASE ASY | 1 | |
| 9 | ELEMENTAIR CLNR | 1 | |
| 10 | GUIDEELEMENT | 1 | |
| 11 | GUIDEELEMENT | 1 | |
| 12 | JOINTAIR CLNR 1 | 1 | |
| 13 | JOINT | 1 | |
| 14 | CAPCLEANER CASE 1 | 1 | |
| 15 | GROMMET | 1 | |
| 16 | FLAP | 1 | |
| 17 | DAMPER 2 | 1 | |
| 18 | HOOK | 1 | |
| 19 | PLATECLNR CS FTNG | 2 | |
| 20 | RIVETBLIND | 6 | |
| 21 | WASHER (5 per pack) | 4 | |
| 22 | STAY 1 | 1 | |
| 23 | BOLTWING | 1 | |
| 24 | SEAL | 1 | |
| 25 | CLIP | 1 | |
| 26 | SEAL | 1 | |
| 27 | WASHERPLATE | 7 | |
| 29 | BAND | 1 | |
| 31 | CLAMPHOSE | 2 | |
| 32 | .BOLT FLANGE | 3 | |
| 33 | SCREWPAN HEAD | 6 | |
| 34 | WASHER (1RW) | 6 |
