Наименование |
Примечание |
Кол-во |
| 1 |
PANELINNER FENDER-ROUTED (HDX)
|
|
1 |
| 2 |
CLIPU-NUT M6 (5 per pack)
|
|
17 |
| 3 |
SCREWFUEL TANK MOUNT (M6X18 DP) (4 per pack)
|
|
10 |
| 4 |
BOOTSTEERING-EPS (DIE CUT)
|
|
1 |
| 5 |
RIVETPLASTIC-REINSTALLABLE (5 per pack)
|
|
4 |
| 6 |
SCREWSELF TAP-TSTRH tahos_10-12X3/4 TP A BLK (5 per pack)
|
|
0 |
| 7 |
BRACKETKICK PANEL-PTD BLACK
|
|
2 |
| 8 |
PANELSIDE KICK
|
|
2 |
| 9 |
SCREWMACH-TSPNH M6X1.0X25 CL8.8 BLK (5 per pack)
|
|
4 |
| 10 |
SCREWMACH-TSTRH-M6-1.0 X 16 BLACK (5 per pack)
|
|
4 |
| 11 |
TONGUEBUCKLE
|
|
2 |
| 12 |
NUTLOCK M6X1 (2 per pack)
|
|
4 |
| 13 |
BRACKETSUPPORT-LH-PTD BLK
|
|
1 |
| 13 |
BRACKETSUPPORT-RH-PTD BLK
|
|
1 |
| 14 |
GROMMETGAUGE MOUNT (3 per pack)
|
|
2 |
| 15 |
SCREW HEXDOME HEAD SHOULDER-1/4-20X.50
|
|
2 |
| 16 |
WASHERFLAT- 1/4 X .625 X .065 Z&Y (10 per pack)
|
|
2 |
| 17 |
FENDERFRONT RH-VIBE MET RED-PTD
|
|
1 |
| 17 |
FENDERFRONT LH-VIBE MET RED-PTD
|
|
1 |
| 18 |
NUTHEX FLG-TOP LOCK 1/4-20 GR F Z&Y (10 per pack)
|
|
2 |
| 19 |
BRACKETFLOOR SUPPORT-PAINTED
|
|
1 |
| 20 |
SCREWMACH-TSTRH M6X1.0X16 Z&Y (5 per pack)
|
|
4 |
| 21 |
FLOOR- PROWLERS
|
|
1 |
| 22 |
SCREWBODY-SELF TAP tahos_12 X 3/4 A Z&B (5 per pack)
|
|
8 |
| 23 |
BRACKETKICK PANEL-LH-PTD BLACK
|
|
1 |
| 23 |
BRACKETKICK PANEL-RH-PTD BLACK
|
|
1 |
| 24 |
SCREWMACH-TSPNH M6X1.0X70 CL8.8 BLK
|
|
2 |
| 25 |
BRKTSUB-FLOOR MOUNTING
|
|
1 |
| 26 |
FLOOR SUB
|
|
1 |
| 27 |
GROMMETCUPHOLDER
|
|
1 |
| 28 |
WASHERFLAT-M8-9.12 X 25.40 X 2.30Z&Y (8 per pack)
|
|
2 |
| 29 |
SCREWMACH-TSTRH M6X1.0X30 Z&Y (4 per pack)
|
|
2 |
| 30 |
SCREWMACH-TSPNH M6X1.0X55 CL8.8 BLK (5 per pack)
|
|
2 |
| 31 |
SUPPORT-SIDE-STORAGE-RH PTD BLK
|
|
1 |
| 31 |
SUPPORT-SIDE-STORAGE-LH PTD BLK
|
|
1 |
| 32 |
SCREWSELF TAP-TSTH 10-12X1/2 WO/GP (10 per pack)
|
|
4 |
| 33 |
SCREWMACH-TSTRH M8X1.25X16 Z&Y
|
|
2 |
| 34 |
SCREWSHOULDER 11 X 3.5 X 6MM (4 per pack)
|
|
2 |
| 35 |
NUTHEX FLG-NYL LOCK M6X1.0 CL8 Z&Y (5 per pack)
|
|
14 |
| 36 |
BOXSIDE STORAGE-LH-SERV ASSY (inc. 37-44 and 12 No. 35)
|
|
1 |
| 36 |
BOXSIDE STORAGE-RH-SERV ASSY (inc. 37-44 and 12 No. 35)
|
|
1 |
| 37 |
PLATEFACE-SIDE STORAGE-PTD BLK
|
|
2 |
| 38 |
SCREWMACH-TSTRH M6X1.0X16 Z&BLK (5 per pack)
|
|
12 |
| 39 |
SEALDOOR-SIDE STORAGE
|
|
2 |
| 40 |
DOORSIDE STORAGE-PTD BLACK
|
|
2 |
| 41 |
LATCHSLIDE
|
|
2 |
| 42 |
HINGEFRICTION (inc. 33)
|
|
4 |
| 43 |
NUTSTAMPED-3/16" (8 per pack)
|
|
16 |
| 44 |
SPACER HINGE (2 per pack)
|
|
4 |
