Наименование |
Примечание |
Кол-во |
| 80 |
PEDALE ACC. *PEDAL-THROTTL
|
|
1 |
| 90 |
BUSHING
|
|
2 |
| 95 |
ECROU PRESSION *PUSH-NUT
|
|
2 |
| 100 |
Hex. Flanged Nut M8
|
|
2 |
| 103 |
CONICAL SPRING WASHER M12 500 F. (5.000 per pack)
|
|
1 |
| 104 |
Hex. Flanged Screw M12 X 30, Scotch Grip
|
|
1 |
| 105 |
DAMPER
|
|
2 |
| 108 |
FRONT ENGINE BRACKET
|
|
1 |
| 109 |
HEX. FLANGED SCREW M10 X 135
|
|
2 |
| 110 |
Flanged Elastic Nut M10
|
|
2 |
| 111 |
Hex. Flanged Screw M6 X 16
|
|
5 |
| 112 |
Hex. Flanged Elastic Nut M6
|
|
5 |
| 115 |
TAMPON ANCRAGE *RUBBER MOUNT
|
|
2 |
| 119 |
SCREW HEXAGONAL CAP M8 X 60 DIN 933
|
|
2 |
| 120 |
BUSHING
|
|
2 |
| 122 |
FLAT WASHER M8
|
|
4 |
| 130 |
BRACKET-LINK
|
|
1 |
| 140 |
BRACKET-ENGINE
|
|
1 |
| 145 |
BRACKET-ENGINE
|
|
1 |
| 146 |
HEX. FLANGED SCREW M8 X 20 (10.000 per pack)
|
|
6 |
| 148 |
Hex. Flanged Elastic Nut M8
|
|
6 |
| 200a |
DUCT
|
|
1 |
| 203 |
NORMA CLAMP
|
|
1 |
| 205 |
ADAP-FLEX.
|
|
1 |
| 214 |
NORMA CLAMP
|
|
1 |
| 215 |
ADAP-FLEX.
|
|
1 |
| 220 |
ADAP.FLEXIBLE *ADAP-FLEX.
|
|
1 |
| 225 |
DUCT
|
|
1 |
| 240 |
CVT FILTER
|
|
1 |
| 250 |
Hex. Flanged Plastite Screw M4.8 X 16
|
|
1 |
| 255 |
WASHER M5 (10.000 per pack)
|
|
1 |
| 270 |
ADAP-FLEX.
|
|
1 |
| 272 |
DUCT
|
|
1 |
| 273 |
Tie-Rap 350 mm
|
|
1 |
| 302 |
Hex. Flanged Screw M8 X 20, Scotch Grip
|
|
2 |
| 303 |
Hex. Flanged Screw M6 X 16, Scotch Grip
|
|
1 |
| 410 |
LEVER Engine 450
|
|
1 |
| 411 |
PIVOT PLATE
|
|
1 |
| 412 |
SPRING Engine 450
|
|
1 |
| 413 |
BUSHING Engine 450
|
|
1 |
| 414 |
HEX. FLANGED SCREW M6 X 40 (5.000 per pack)
|
|
1 |
| 420 |
Hex. Flanged Screw M6 X 30, Scotch Grip
|
|
1 |
| 440 |
CABLE SUPPORT
|
|
1 |
| 470 |
CABLE D EMBRAYA*SHIFTING CABLE
|
|
1 |
| 475 |
PASSE-FILS *GROMMET-CABLE
|
|
1 |
| 480 |
Hex. Elastic Stop Nut M8
|
|
2 |
| 490 |
Flat Washer 8 mm
|
|
2 |
| 500 |
SHIFTER BRAKET
|
|
1 |
| 505 |
CABLE SUPPORT
|
|
1 |
| 510 |
LOWER SHIFTER ARM
|
|
1 |
| 512 |
VENTURI BUSHING (5.000 per pack)
|
|
2 |
| 513 |
DOUILLE INT. *BUSHING-INT.
|
|
1 |
| 514 |
Flat Washer 8 mm
|
|
2 |
| 515 |
HEX. FLANGED SCREW M8 X 60 (10.000 per pack)
|
|
1 |
| 520 |
WELDED ARM
|
|
1 |
| 521 |
FLANGED BUSHING
|
|
2 |
| 522 |
BUSHING
|
|
1 |
| 523 |
HEX. FLANGED SCREW M6 X 50 Model-550F (3.000 per pack)
|
|
1 |
| 530 |
LEVER ARM SPRING
|
|
1 |
| 540 |
LEVER BUTTON
|
|
1 |
| 541 |
Hex. Jam Nut M8
|
|
1 |
| 550 |
SHIFTER ARM COVER
|
|
1 |
| 1430 |
HEX. SCREW M4 X 25 Australia Model (4.000 per pack)
|
|
2 |
| 1435 |
Flat Washer 4 mm
|
|
4 |
| 1440 |
Elastic Stop Nut M4
|
|
2 |
| 1445 |
IGNITION COIL BRACKET
|
|
1 |
| 1450 |
Hex. Flanged Screw M6 X 20
|
|
1 |
