Наименование |
Примечание |
Кол-во |
| 10>10c |
ETRIER GAUCHE *LH CALIPER LH Front
|
|
1 |
| 10a |
ENS.PLAQ. FREIN*KIT PAD-BRAKE FL LH Front. Incl 10c
|
|
1 |
| 10a1 |
ENSEMBLE GOUP. *PIN-SET
|
|
1 |
| 10b |
BLEEDING SCREW
|
|
1 |
| 10c |
SPRING BOOT KIT
|
|
1 |
| 20>20c |
ETRIER DROIT *RH CALIPER RH Front
|
|
1 |
| 20a |
ENS.PLAQ. FREIN*KIT PAD-BRAKE FR RH Front. Incl 10c
|
|
1 |
| 30>30b |
MASTER CYLINDER
|
|
1 |
| 30a |
OIL TANK
|
|
1 |
| 30b |
HOUSING OIL HOSE
|
|
1 |
| 40>40a |
BRAKE HOSE Package BASE STD DPS Includes 40 to 40a
|
|
1 |
| 40>40a |
BRAKE HOSE Package CAB Includes 40 to 40a
|
|
1 |
| 40a |
Hose Clip
|
|
2 |
| 45<45a |
BRAKE HOSE Includes 45 to 45a
|
|
1 |
| 45<45a |
BRAKE HOSE Package CAB Includes 45 to 45a
|
|
1 |
| 45<45a |
BRAKE HOSE Includes 45 to 45a
|
|
1 |
| 45<45a |
BRAKE HOSE Includes 45 to 45a
|
|
1 |
| 45a |
HOSE CLIP Not Shown
|
|
5 |
| 50 |
Banjo Bolt (M10 x 1.25 thread)
|
|
0 |
| 60 |
Copper Washer
|
|
0 |
| 95 |
Hex. Flanged Elastic Nut M8
|
|
2 |
| 100 |
Clamp
|
|
2 |
| 140 |
Pop Rivet 3/16"
|
|
0 |
| 145 |
Pop Rivet 3/16"
|
|
2 |
| 150 |
BRAKE SWITCH Model-North America International
|
|
1 |
| 155 |
HEX. SCREW M6 X 16 SCOTCH GRIP (25.000 per pack)
|
|
2 |
| 170>170c |
ETRIER GAUCHE *LH.CALIPER LH Rear
|
|
1 |
| 170>170d |
ETRIER GAUCHE *LH.CALIPER Includes 170 to 170d
|
|
1 |
| 170a |
KIT PAD-BRAKE
|
|
1 |
| 170a |
ENS.PLAQ. FREIN*KIT PAD-BRAKE RL LH Rear. Incl 10c
|
|
1 |
| 180>180c |
ETRIER DROIT *RH.CALIPER RH Rear
|
|
1 |
| 180>180d |
ETRIER DROIT *RH.CALIPER Includes 180 to 180d
|
|
1 |
| 180a |
ENS.PLAQ. FREIN*KIT PAD-BRAKE RR RH Rear. Incl 10c
|
|
1 |
| 180a |
KIT PAD-BRAKE RR
|
|
1 |
| 200 |
Torx Screw K50 X 16
|
|
2 |
| 210 |
Clip
|
|
1 |
| 220 |
Flat Washer 6 mm
|
|
2 |
| 230 |
GROMMET (5.000 per pack)
|
|
2 |
| 250 |
PEDALE FREIN *PEDAL-BRAKE
|
|
1 |
| 260 |
BRAKE PEDAL SPRING
|
|
1 |
| 300 |
O-RING
|
|
2 |
| 350 |
DOUILLE INT. *BUSHING-INT.
|
|
1 |
| 360 |
FLANGED HEX. SCREW M10 X 130
|
|
1 |
| 370 |
Flanged Elastic Nut M10
|
|
1 |
| 385 |
DISC BRAKE
|
|
0 |
| 390 |
Torx Screw M8 X 16, Scotch Grip
|
|
0 |
| 445 |
HEX. FLANGED SCREW M10 X 25
|
|
0 |
