Наименование |
Примечание |
Кол-во |
| 1 |
COTTER PIN 10 PK (010 per pack)
|
|
1 |
| 2 |
PROP NUT
|
|
1 |
| 3 |
PROP AL. 9.25X11
|
|
1 |
| 3 |
PROP ALUM9X10
|
|
1 |
| 3 |
PROPAL 9X9 3BLD
|
|
1 |
| 3 |
Детать
|
|
1 |
| 3 |
Детать
|
|
1 |
| 3 |
Детать
|
|
1 |
| 3 |
PROP AYAL 9.25X12
|
|
1 |
| 4 |
PROP HUB 25 HP Use Only with Propeller P/N 389067
|
|
1 |
| 5 |
SCREW
|
|
4 |
| 6 |
SCREW (005 per pack)
|
|
2 |
| 7 |
LOCKWASHER
|
|
2 |
| 8 |
CONNECTORSHFT ROD
|
|
1 |
| 8 |
CONNECTORSHFT ROD 20 INCH (508mm) LONG PARTS
|
|
1 |
| 9 |
(25WRL.)
|
|
1 |
| 9 |
WTR TUBE AY
|
|
1 |
| 9 |
WTR TUBE AY 22.5 INCH (572mm) LONG PARTS
|
|
1 |
| 10 |
(Optional.)
|
|
1 |
| 11 |
GROMMET (005 per pack)
|
|
1 |
| 13 |
SCREW
|
|
4 |
| 14 |
IMP HSG
|
|
1 |
| 15 |
WASHER 22.5 INCH (572mm) LONG PARTS
|
|
1 |
| 16 |
DRIVESHAFT 22.5 22.5 INCH (572mm) LONG PARTS
|
|
1 |
| 16 |
DRIVESHAFT15"
|
|
1 |
| 16 |
DRIVESHAFT20" 20 INCH (508mm) LONG PARTS
|
|
1 |
| 17 |
GASKET
|
|
1 |
| 18 |
PLATE Chrome Plated
|
|
1 |
| 18 |
PLATE Stainless Steel
|
|
1 |
| 19 |
SCREW (004 per pack)
|
|
2 |
| 20 |
COVER
|
|
1 |
| 21 |
COTTER PIN
|
|
1 |
| 22 |
PIN
|
|
1 |
| 23 |
LEVER & PIN A
|
|
1 |
| 24 |
CRADLE-CLUTCH DOG
|
|
1 |
| 25 |
SHIFT RODLOW-STD Optional
|
|
1 |
| 25 |
SHIFT RODLOW-LONG 20 INCH (508mm) LONG PARTS
|
|
1 |
| 25 |
SHIFT ROD-LOWER 22.5 INCH (572mm) LONG PARTS
|
|
1 |
| 26 |
GCASE HEAD&SEAL AY
|
|
1 |
| 27 |
OIL RETAINER
|
|
1 |
| 28 |
SEAL PROP SHAFT
|
|
1 |
| 29 |
GEAR-REVERSE3LUG
|
|
1 |
| 30 |
BUSHING
|
|
1 |
| 31 |
O-RING (005 per pack)
|
|
1 |
| 32 |
SHIFTER 3 LUG
|
|
1 |
| 33 |
Детать
|
|
1 |
| 34 |
GEAR&BUSH-FWD3LUG
|
|
1 |
| 35 |
BEARING-FWD GEAR
|
|
1 |
| 36 |
PINION-DRIVESHAFT
|
|
1 |
| 37 |
G-CASE & BRG
|
|
1 |
| 38 |
GASKET
|
|
1 |
| 39 |
BRG AY NEEDLE
|
|
1 |
| 41 |
OIL RETAINER
|
|
1 |
| 42 |
BUSHING J 2PK (002 per pack)
|
|
1 |
| 43 |
O RING Contents of Gearcase Seal Kit (005 per pack)
|
|
1 |
| 44 |
PLUG
|
|
1 |
| 45 |
SCREEN
|
|
1 |
| 46 |
DRAIN FILL PLG 10P (010 per pack)
|
|
2 |
| 47 |
O-RING (010 per pack)
|
|
1 |
| 47 |
WASHER-10 PK (010 per pack)
|
|
1 |
| 48 |
PIVOT PIN & WASHER
|
|
1 |
| 49 |
WASHER 5PK (005 per pack)
|
|
1 |
| 50 |
SCREW (005 per pack)
|
|
6 |
| 51 |
DOWEL (Contents of Water Pump Repair Kit. RL RVL EL EVL Models.)
|
|
1 |
| 52 |
BEARING AY
|
|
1 |
| 53 |
MAGNET
|
|
1 |
| 55 |
THRUST BRG AY
|
|
1 |
| 56 |
FF THRUST WASHER
|
|
1 |
| 57 |
THRUST WASHER-LWR
|
|
1 |
| 58 |
THRUST WASHER
|
|
1 |
| 59 |
Детать
|
|
1 |
| 60 |
DETENT SPRING
|
|
1 |
| 61 |
BALL DETENT (005 per pack)
|
|
2 |
| 62 |
IMP & KEY
|
|
1 |
| 63 |
KEYIMPELLER-BLK
|
|
1 |
| 64 |
CUP-CHROME Optional accessory
|
|
1 |
| 64 |
CUP IMP HSG
|
|
1 |
| 65 |
GASKET-IMPELLR 5PK Also included in kit 396352 (005 per pack)
|
|
1 |
| 66 |
STUD 22.5 INCH (572mm) LONG PARTS
|
|
1 |
| 66 |
20 INCH (508mm) LONG PARTS
|
|
1 |
| 67 |
NUT
|
|
1 |
| 68 |
O RING
|
|
2 |
| 69 |
22.5 INCH (572mm) LONG PARTS
|
|
1 |
| 69 |
SPACER 20 INCH (508mm) LONG PARTS
|
|
1 |
| 71 |
20 INCH (508mm) LONG PARTS
|
|
1 |
| 71 |
EXTENSION & STUD 22.5 INCH (572mm) LONG PARTS
|
|
1 |
| 72 |
22.5 INCH (572mm) LONG PARTS
|
|
1 |
| 73 |
22.5 INCH (572mm) LONG PARTS
|
|
2 |
| 74 |
Детать
|
|
1 |
| 75 |
KIT AY WTR PUMP
|
|
1 |
| 76 |
ZINC ANODE KIT OB
|
|
1 |
| 77 |
SEAL KIT-G-CASE
|
|
1 |
| 0304454 |
LOCKWASHER
|
|
2 |
| 0306643 |
SCREW
|
|
2 |
| 0325974 |
RUBBER MOUNT
|
|
2 |
| 0325975 |
RUBBER MOUNT
|
|
2 |
| 0332226 |
SCREW
|
|
1 |
| 0396262 |
Not Shown 20 INCH (508mm) LONG PARTS
|
|
1 |
