| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| - | GC 25/30 4S LG Long | 1 | |
| - | REPAIR KIT W/P | 1 | |
| - | GASKET SET L/U | 1 | |
| - | GC 25/30 4S SH Short | 1 | |
| 1 | GC BASIC 25/30 4S | 1 | |
| 2 | BEARING | 1 | |
| 3 | PLUG-OIL | 2 | |
| 4 | ORD 8M0082880 | 2 | |
| 5 | STRAINER SET | 1 | |
| 6 | SCREW | 1 | |
| 7 | NUT | 1 | |
| 8 | STRAINER | 1 | |
| 9 | SCREW | 1 | |
| 10 | TRIM TAB | 1 | |
| 11 | BOLT | 1 | |
| 12 | NUT | 1 | |
| 13 | GEAR-PINION | 1 | |
| 14 | SPRING | 1 | |
| 15 | GUIDE | 1 | |
| 16 | DRIVESHAFT-LONG Long | 1 | |
| 16 | DRIVESHAFT-SHORT Short | 1 | |
| 17 | KEY | 1 | |
| 18 | BEARING ASSY | 1 | |
| 19 | SHIM | 0 | |
| 19 | SHIM (.15) | 0 | |
| 19 | SHIM (.3) | 0 | |
| 19 | SHIM (.5) | 0 | |
| 20 | OIL SEAL | 1 | |
| 21 | O RING | 1 | |
| 22 | HOUSING-W/P | 1 | |
| 23 | DOWEL PIN | 2 | |
| 24 | GASKET | 1 | |
| 25 | GUIDE PLATE W/P | 1 | |
| 26 | GASKET | 1 | |
| 27 | IMPELLER | 1 | |
| 28 | HOUSING-W/P | 1 | |
| 29 | LINER-PUMP HSG. | 1 | |
| 30 | SEAL | 1 | |
| 31 | BOLT | 4 | |
| 32 | GROMMET | 1 | |
| 33 | WATER TUBE SHORT | 1 | |
| 33 | WATER TUBE LONG Long | 1 | |
| 34 | ORD 32-8M0093642 Long | 1 | |
| 35 | BOLT Long | 1 | |
| 36 | WASHER | 5 | |
| 37 | STUD BOLT Short | 1 | |
| 38 | NUT Short | 1 | |
| 39 | BOLT | 4 |
