| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| - | GASKET SET | 0 | |
| 1 | GASKET @2 (2 per pack) | 2 | |
| 2 | PLATE | 1 | |
| 3 | SEAL | 1 | |
| 4 | COVER | 1 | |
| 5 | SCREW @5 (5 per pack) | 21 | |
| 6 | COVER ASSY | 1 | |
| 7 | SCREW @5 (5 per pack) | 2 | |
| 8 | GASKET @2 (2 per pack) | 2 | |
| 9 | PLATE ASSY | 1 | |
| 10 | DIAPHRAGM | 1 | |
| 11 | WASHER @2 (2 per pack) | 1 | |
| 12 | SCREW | 1 | |
| 13 | SPRING | 1 | |
| 14 | POPPET | 1 | |
| 15 | GROMMET @2 (2 per pack) | 1 | |
| 16 | CARRIER | 1 | |
| 17 | COVER ASSY | 1 | |
| 19 | GASKET @2 (2 per pack) | 2 | |
| 20 | PLATE KIT | 1 | |
| 21 | DIAPHRAGM | 1 | |
| 22 | DEFLECTOR | 1 | |
| 26 | POPPET | 1 | |
| 29 | WASHER | 1 | |
| 30 | EXHAUST EXT PLATE | 1 | |
| 30 | EXHAUST EXT PLATE | 1 | |
| 31 | ELBOW | 1 | |
| 32 | PIN-DOWEL-SOLID | 2 | |
| 33 | SEAL | 1 | |
| 34 | BRACKET | 1 | |
| 35 | SCREW @5 (5 per pack) | 8 | |
| 36 | WASHER @5 (5 per pack) | 6 | |
| 37 | NUT @5 (5 per pack) | 6 | |
| 38 | BUSHING | 1 | |
| 39 | SCREW @5 (5 per pack) | 1 | |
| 40 | SCREW @3 (3 per pack) | 1 | |
| 41 | SCREW | 3 | |
| 42 | GROMMET | 1 | |
| 43 | PLATE | 1 | |
| 44 | GROMMET-WATER TUB | 1 | |
| 45 | SCREW @5 (5 per pack) | 13 | |
| 46 | WASHER (10 per pack) | 13 | |
| 47 | NUT @2 (2 per pack) | 13 | |
| 48 | GASKET | 1 |
