| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | HOSEWATER RETU | 1 | |
| 2 | HOSEWATER RETU | 1 | |
| 3 | PLATE COMPCYL | 1 | |
| 4 | GASKETCYLINDER | 1 | |
| 5 | PIPEWATER OUTL | 2 | |
| 6 | GASKETWTR OUTL | 2 | |
| 7 | COVERWTR PRESS | 1 | |
| 8 | VALVEWTR PRESS | 1 | |
| 9-1 | THERMOSTATWATE | 2 | |
| 9-2 | THERMOSTAT (OPT) | 1 | |
| 10 | COVERTHERMOSTA | 2 | |
| 11 | 3WAYWATER HOSE | 1 | |
| 12 | HOSEWATER(3WAY | 1 | |
| 13 | BOLT | 2 | |
| 14 | O RING D:3.1 ID | 1 | |
| 15 | Детать | 1 | |
| 16 | HOSE 5X9X600 (L:600->100) | 1 | |
| 23 | HOSE (L2000->850L:2000->1010) | 1 | |
| 25 | BOLT 8 X 12 | 1 | |
| 26 | 3 WAY JOINT | 1 | |
| 27 | CLIP | 18 | |
| 28 | CLIP | 2 | |
| 29 | CLIP | 4 | |
| 30 | Детать | 1 | |
| 31 | CLAMP | 1 | |
| 32 | (<-09408-00056) | 1 | |
| 33 | BOLT | 6 | |
| 35 | BOLT | 10 | |
| 36 | HOLDERWATER HO | 1 | |
| 37 | CLIP | 2 | |
| 38 | HOSEWATER FLUS | 1 | |
| 39 | CLAMP FUEL HOSE | 1 | |
| 40 | Детать | 1 | |
| 41 | BRACKETHARNESS | 1 |
