| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | PARTS ASSY REMO | 1 | |
| 2 | ROD COMPTHROTT | 1 | |
| 3 | PIN | 1 | |
| 4 | LEVERTHROTTLE | 1 | |
| 5 | CONNECTORTHROT | 1 | |
| 6 | DRUMTHROTTLE | 1 | |
| 7 | SPRINGTHROTTLE | 1 | |
| 8 | HARNESS ASSYWI (DF9.9R) | 1 | |
| 9 | CAPOIL PRESSUR | 1 | |
| 10 | ATTACHMENTSTEE ( REFER TO FIG.70(J- 4) FOR MODEL:05~ ) | 1 | |
| 11 | ATTACHMENTSTEE (MODEL:05~09) | 1 | |
| 12 | PIN ( REFER TO FIG.41(F- 9) FOR TYPE:T/TH ) | 1 | |
| 13 | GROMMETSIDE CO (DF9.9R MODEL:05~09 ) | 1 | |
| 14 | HOLDERR/CON CA (CLUTCH MODEL:05~09 ) | 1 | |
| 15 | HOLDER COMPR/C (THROTTLE MODEL:05~09 ) | 1 | |
| 16 | CABLE CONNECTOR | 1 | |
| 17 | CONNECTORREMOC | 1 | |
| 18 | STUD BOLT | 2 | |
| 19 | BOLT | 1 | |
| 20 | BOLT6X15 | 1 | |
| 21 | NUT | 2 | |
| 22 | WASHER | 1 | |
| 23 | WASHER (<-09162-08007) | 2 | |
| 24 | GROMMET | 1 | |
| 25 | CLAMP (L:145) | 2 | |
| 26 | CLAMP (L:95) | 2 | |
| 27-1 | BOLT | 1 | |
| 27-2 | BOLT (NOT ILLUSTRATED) | 1 | |
| 28 | WASHER (0010 per pack) | 1 | |
| 29 | CUSHIONREMOCON (MODEL:06~09) | 1 |
