| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | HOSE WITH SPRING | 1 | |
| 2 | CLAMP | 1 | |
| 3 | WIRELEAD | 1 | |
| 4 | BOLT | 2 | |
| 5 | WASHER (5 per pack) | 2 | |
| 7 | BATTERY CABLE | 1 | |
| 8 | NUT (6L2) | 2 | |
| 9 | WASHERSPRING | 2 | |
| 10 | WIRE LEAD | 1 | |
| 11 | WIRE HARNESS ASSY | 1 | |
| 12 | CLAMP (5 per pack) | 1 | |
| 13 | TUBE | 1 | |
| 16 | CLAMP | 3 | |
| 19 | WIRE HARNESS ASSY 2 | 1 | |
| 21 | CLAMP | 1 | |
| 23 | CLAMP | 1 | |
| 25 | TRIM & TILT SWITCH A | 1 | |
| 26 | GASKET | 2 | |
| 27 | COVER BOTTOM | 1 | |
| 28 | BRACKET | 1 | |
| 29 | BRACKET | 1 | |
| 30 | BRACKET | 1 | |
| 31 | CLAMP | 2 | |
| 32 | BOLT | 1 | |
| 33 | BOLT | 4 | |
| 34 | PLATE | 1 | |
| 35 | GROMMET | 1 | |
| 36 | SENSOR PRESSURE | 1 | |
| 37 | SCREWPAN HEAD (5 per pack) | 2 | |
| 38 | PLATE | 2 | |
| 39 | BOLT | 2 |
