| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| KIT-LORD 406 REPAIR KIT 50ML [ADHESIVE] | 1 | ||
| KIT-LORD MIX NOZZLES | 1 | ||
| KIT-LORD 406 50ML CARTRIDGE [ADHESIVE] | 1 | ||
| 1 | SCREW(10) (10 per pack) | 3 | |
| 2 | CLIP DART | 2 | |
| 3 | ASM-CLIP F/CRH [INCL. 17][REQUIRES ADHESIVE] | 1 | |
| 4 | NUT-M8X1.25FLGNYLOC-OLIVE D | 9 | |
| 5 | SCR-TXTH-M8X1.25X25 8.8 ZODP30 | 6 | |
| 6 | CL8.8 OLV-D | 5 | |
| 7 | BRACE-LOWER RH MACH [REQUIRES ADHESIVE] | 1 | |
| 8 | FLOOR-BULKHEADVENTED | 1 | |
| 9 | VENT-FLOOR | 1 | |
| 10 | RIVETINTERLOCKZ(50) * (50 per pack) | 10 | |
| 11 | SCR-M10X1.5X25-8.8 HFS ZOD | 2 | |
| 12 | TUBE-CROSSM10X1.5377.44MM | 1 | |
| 13 | ASM-BRACE LOWER LH [REQUIRES ADHESIVE][INCL. SLEEVE] | 1 | |
| 14 | ASM-CLIP F/CLH [INCL. 17][REQUIRES ADHESIVE] | 1 | |
| 15 | SCR-HXFL-M8X1.25X25 8.8 ZODP30 | 6 | |
| 16 | BRKT-PIPE/CHASSIS | 1 | |
| 17 | STUD-WHEEL M8X1.25X48 | 14 | |
| 18 | REINFORCEMENT-CLIP PLATED LH | 1 | |
| 18 | REINFORCEMENT-CLIPRH | 1 | |
| 19 | BOOT-TIE ROD | 2 | |
| 20 | PLATE-BOOT SEALLHBLK | 1 | |
| 20 | PLATE-BOOT SEALRHBLK | 1 |
