| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | DEEP BLACK FRONT BOTTOM PAN | 1 | |
| 2 | Pop Rivet 3/16" | 12 | |
| 3 | RH FOAM UPPER | 1 | |
| 4 | LH FOAM UPPER | 1 | |
| 5 | RH MIDDLE FOAM | 1 | |
| 6 | LH MIDDLE FOAM | 1 | |
| 7 | RH LOWER FOAM | 1 | |
| 8 | LH LOWER FOAM | 1 | |
| 9 | DEEP BLACK BOTTOM PAN CAP | 1 | |
| 10 | TORX SCREW M6 X 20 Model-RT STD | 2 | |
| 11 | Panel Nut M6 X 1.0 | 2 | |
| 12 | COQUE DROITE *PAN-BOTTOM RH | 1 | |
| 14 | Black Pop Rivet 3/16" | 1 | |
| 15 | Pop Rivet 3/16" | 1 | |
| 16 | RONDELLE *WASHER (10.000 per pack) | 1 | |
| 17 | TRUSS HEAD TORX SCREW K50 X 16 (5.000 per pack) | 1 | |
| 18 | Nylon Cap | 1 | |
| 19 | DEEP BLACK LH BOTTOM PAN | 1 | |
| 20 | Gasket, Neoprene | 1 | |
| 27 | BOTTOM PAN CAP | 1 | |
| 28 | BLACK FRONT BUMPER | 1 | |
| 29 | Hex. Flanged Screw M6 X 20 | 2 | |
| 30 | Hex. Flanged Elastic Nut M6 | 2 |
